DESCRIPTION :Laser markers are used in a wide range of industrial fields and in various regions around the world, so they are required to provide their function in all types of work environment. In developing the new model, we even considered work environments in which the laser marker was exposed to water drops and dust particles as well as unfavorable power supply conditions. Furthermore, we ensured ease of installation to equipment in designing the product SPECIFICATION : Work distance ; 190mm Marking field : 90mm x 90mm Scanning speed max : 12,000mm/s Line speed max : 240m/min Output class : 20W Ambient temperature : 0 to +40°C Ambient humidity : 35 to 85% RH Marking method : Galvanometer scanning Marking laser : FAYb ? = 1.06µm, laser class 4 Power consumption : Maximum 370 VA (max. 2.1 A) Net weight of head : 8KG Net weight of controller ; 37KG Made In : China Guide laser : Red semiconductor laser; ?= 655 nm; class 2 laser, maximum output 1 Mw
